Счетчик NE214 BAUMER 7727
Артикул: 7727
Цена: по запросу
Есть в наличии
Работаем с 44ФЗ, 223ФЗ, 275ФЗ
Аккредитация на АСТ ГОЗ
Доставка вМосква
Самовывоз из магазина0 руб.
по предварительному заказу
(г. Москва, м. Таганская,
ул. Большие Каменщики, д. 6, стр. 1)
(г. Москва, м. Таганская,
ул. Большие Каменщики, д. 6, стр. 1)
Курьером (1-2 рабочих дня)0 руб.
Самовывоз из ПВЗ (1-2 рабочих дня)0 руб.
ХАРАКТЕРИСТИКИ
Гарантия
- 12 месяцев
Сертификаты
- CE
Storage temperature
- -20…+70 °C
Function
- Preset counter Main counter with 2 presets Batch counter with 1 preset Totalizer Hour counter
Display
- LED, 7-segment display
Number of digits
- 6-digits
Digit height
- 14 mm
Ambient temperature
- 0…+50 °C
Housing type
- Built-in housing
Dimensions W x H x L
- 96 x 48 x 124 mm
Mounting
- Clip frame for built-in housing
Weight approx.
- 350 g (AC) 250 g (DC)
Materials
- Housing: Makrolon 6485 (PC) Keypad: Polyester
Voltage supply
- 24/48 VAC ±10 % (50/60 Hz) 115/230 VAC ±10 % (50/60 Hz) 24 VDC ±10 %
Reset
- Button, electric or automatic
Emitted interference
- DIN EN 61000-6-3
Interference immunity
- DIN EN 61000-6-2
Programmable parameters
- Operating modes Sensor logic Scaling factor Count mode Control inputs
Approval
- UL approval / E63076
Relative humidity
- 80 % non-condensing
Core cross-section
- 1.5 mm
Protection DIN EN 60529
- IP 65 (face with seal)
Mounting depth
- 124 mm
Cutout dimensions
- 92 x 44 mm (-0.6)
Power consumption
- 7 VA 5 W
Sensor supply
- 12…26 VDC / max. 100 mA
Scaling factor
- 0.0001…9999.99
Multitplier / batch counter
- 1…999
Count modes
- Adding or subtracting Difference counting A-B Total (parallel) A+B Up/Down A 90° B phase evaluation
Counting frequency
- 3 Hz, 25 Hz, 10 kHz programmable
Preset
- 2 presets
Operating modes
- Step preset Main preset Parallel alignment Trailing preset
Data memory
- >10 years in EEPROM
Outputs electronic
- Optocoupler
Outputs relay
- Change-over contact, floating
Output holding time
- 0.01…99.99 s
Analog output
- 0(2)…10 V, 0(4)…20 mA
Interfaces
- RS232 RS422 RS485
Standard DIN EN 61010 1
- Protection class II Overvoltage category II Pollution degree 2
Connection
- Plug-in screw terminal connector
Operation / keypad
- Membrane with softkeys
ОПИСАНИЕ
Счетчик NE214 Baumer от Baumer — продукция Счетчики, которая гарантирует эффективность и устойчивость в работе. Компания Baurussia.ru поставляет сертифицированные товары напрямую от производителей
Преимущества работы с нами:
- Гарантированно подлинное оборудование напрямую от бренда
- Поддержка инженеров и менеджеров на каждом этапе сделки
- Конкурентные цены и прозрачные условия работы
- Оперативная обработка заявок и доставка по РФ
- Минимальные сроки доставки за счет прямых поставок
